1565373-4
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 28POS 2.2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1565373-4 Datasheet
-
ECAD Model
- Share
In Stock: 1,565
Can ship immediately
Pricing:
- 1$9.18
- 12$8.77849
- 108$7.38223
- 504$6.1851
- 1,008$5.46682
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.087" (2.20mm)
- Number of Positions:28
- Number of Rows:2
- Row Spacing - Mating:0.118" (3.00mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:0.217" (5.50mm)
- Contact Length - Post:0.157" (4.00mm)
- Overall Contact Length:-
- Insulation Height:0.610" (15.49mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Syndiotactic Polystyrene (SPS), Glass Filled
- Features:Mounting Flange
- Operating Temperature:-30°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:12VDC
