IL-2P-S3EN2-1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 2POS 2.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet IL-2P-S3EN2-1 Datasheet
-
ECAD Model
- Share
In Stock: 1,723
Can ship immediately
Pricing:
- 1$0.58
- 10$0.54
- 100$0.414
- 500$0.36
- 1,000$0.297
- 5,000$0.261
- 10,000$0.243
Quote It
Technical Details
- Series:IL
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.098" (2.50mm)
- Number of Positions:2
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 1 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:0.236" (6.00mm)
- Contact Length - Post:0.138" (3.50mm)
- Overall Contact Length:0.500" (12.70mm)
- Insulation Height:0.382" (9.70mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:3.90µin (0.099µm)
- Contact Finish - Post:-
- Contact Material:Brass
- Insulation Material:Polyamide (PA66), Nylon 6/6
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Brown
- Current Rating (Amps):-
- Voltage Rating:-
