0989971002
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER BRD EDGE 53POS
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0989971002 Datasheet
-
ECAD Model
- Share
In Stock: 377
Can ship immediately
Pricing:
- 1$23.18
- 10$20.92361
- 100$18.16756
- 500$16.66401
Quote It
Technical Details
- Series:CMC 98997
- Package:Bulk
- Part Status:Last Time Buy
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:-
- Number of Positions:53
- Number of Rows:5
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Board Edge, Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Lock
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:1.815" (46.10mm)
- Contact Shape:-
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:157.5µin (4.00µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Board Guide, Board Lock, Mounting Flange
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
