In Stock: 8,563

Can ship immediately

Pricing:
  • 1$0.56
  • 10$0.52578
  • 100$0.40289
  • 500$0.35037
  • 1,000$0.28905
  • 5,000$0.25402
  • 10,000$0.23651

Quote It

Technical Details

  • Series:High Performance Interconnect (HPI)
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Positions:15
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 3 Wall
  • Mounting Type:Through Hole
  • Termination:Press-Fit, Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:0.132" (3.35mm)



  • Contact Length - Post:0.134" (3.40mm)
  • Overall Contact Length:-
  • Insulation Height:0.239" (6.07mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic
  • Features:-
  • Operating Temperature:-25°C ~ 85°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Natural
  • Current Rating (Amps):3A
  • Voltage Rating:250V

Related Products


146134-2

CONN HEADER SMD 6POS 2.54MM

146134-2 Datasheet
  • 1: $0.56000
  • 72: $0.41926
  • 144: $0.40176

77311-818-09LF

CONN HEADER VERT 9POS 2.54MM

77311-818-09LF Datasheet
  • 1: $0.56000
  • 10: $0.52123
  • 100: $0.39975

5-1376492-2

CONN HEADER VERT 2POS 2.5MM

5-1376492-2 Datasheet
  • 1: $0.85000
  • 900: $0.56217
  • 1800: $0.48186

5-1775443-7

CONN HEADER SMD 7POS 1.5MM

5-1775443-7 Datasheet
  • 1: $0.97000
  • 800: $0.60923
  • 1600: $0.53111

2-292132-3

CONN HEADER VERT 3POS 2MM

2-292132-3 Datasheet
  • 1: $0.58000
  • 10: $0.55051
  • 100: $0.42969

0022280031

CONN HEADER VERT 3POS 2.54MM

0022280031 Datasheet
  • 1: $0.58000
  • 10: $0.54300
  • 100: $0.41630

0532900680

CONN HEADER VERT 6POS 2MM

  • 1: $0.59000

53025-12-0100-01

WIRE-TO BOARD WAFER, 2.5MM, 12 C

  • 1: $0.58000

0026202031

CONN HEADER VERT 3POS 3.96MM

0026202031 Datasheet
  • 1: $0.58000
  • 10: $0.54200
  • 100: $0.41540

644168-1
