53025-14-0100-01

CnC Tech
In Stock: 7,155

Can ship immediately

Pricing:
  • 1$0.67

Quote It

Technical Details

  • Series:-
  • Package:Tube
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.098" (2.50mm)
  • Number of Positions:14
  • Number of Rows:2
  • Row Spacing - Mating:0.098" (2.50mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:-



  • Contact Length - Post:0.134" (3.40mm)
  • Overall Contact Length:-
  • Insulation Height:0.287" (7.30mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyamide (PA66), Nylon 6/6, Glass Filled
  • Features:-
  • Operating Temperature:-25°C ~ 85°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:White
  • Current Rating (Amps):3A (AC/DC)
  • Voltage Rating:250VAC/DC

Related Products


1-2132415-2

CONN HEADER VERT 12POS 2.5MM

1-2132415-2 Datasheet
  • 1: $0.67000
  • 10: $0.63231
  • 100: $0.48481

1041300510

CONN HEADER SMD 5POS 1.25MM

1041300510 Datasheet
  • 1: $1.31000
  • 1500: $0.67725
  • 3000: $0.65468

292251-8

CONN HEADER VERT 8POS 2MM

292251-8 Datasheet
  • 1: $0.68000
  • 10: $0.63570
  • 100: $0.48764

3-1376382-4

CONN HEADER VERT 2POS 5MM

3-1376382-4 Datasheet
  • 1: $0.68000
  • 10: $0.63300
  • 100: $0.48540

7-1747072-4

CONN HEADER VERT 4POS 2.5MM

7-1747072-4 Datasheet
  • 1: $1.40000
  • 450: $1.06011
  • 900: $0.93966

1-440054-1

CONN HEADER VERT 11POS 2MM

1-440054-1 Datasheet
  • 1: $0.69000
  • 10: $0.60493
  • 100: $0.52175

2-292132-4

CONN HEADER VERT 4POS 2MM

2-292132-4 Datasheet
  • 1: $0.69000
  • 10: $0.64821
  • 100: $0.50652

54025-06-0100-01

WIRE-TO BOARD WAFER, 2.5MM, 6 CO

  • 1: $0.70000

0026192031

CONN HEADER VERT 3POS 3.96MM

0026192031 Datasheet
  • 1: $0.70000
  • 10: $0.65300
  • 100: $0.50050

0010977085
