BM18B-ZPDSS-TF(LF)(SN)
JST
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER SMD 18POS 1.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet BM18B-ZPDSS-TF(LF)(SN) Datasheet
-
ECAD Model
- Share
In Stock: 958
Can ship immediately
Pricing:
- 1$1.55
- 1,000$0.8617
- 2,000$0.83298
- 3,000$0.80425
- 5,000$0.76404
- 10,000$0.74681
Quote It
Technical Details
- Series:ZPD
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Connector Type:Header
- Contact Type:Outer Shroud Contact
- Pitch - Mating:0.059" (1.50mm)
- Number of Positions:18
- Number of Rows:2
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.219" (5.56mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polyamide (PA), Nylon
- Features:Solder Retention
- Operating Temperature:-25°C ~ 85°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):2A
- Voltage Rating:100V
