1-1827581-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 3POS
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1-1827581-1 Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
- 1$1.83
- 10$1.66234
- 100$1.42505
- 500$1.18754
- 1,000$1.01789
- 5,000$0.90253
- 10,000$0.88217
Quote It
Technical Details
- Series:Dynamic D-1500
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Tab
- Pitch - Mating:-
- Number of Positions:3
- Number of Rows:3
- Row Spacing - Mating:0.130" (3.30mm)
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Detent Lock
- Contact Length - Mating:-
- Contact Length - Post:0.120" (3.05mm)
- Overall Contact Length:-
- Insulation Height:0.490" (12.44mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:15.0µin (0.38µm)
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic, Polyester, Glass Filled
- Features:Board Lock
- Operating Temperature:-55°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):5A
- Voltage Rating:250V
