850-10-003-10-003000
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 3POS 1.27MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 850-10-003-10-003000 Datasheet
-
ECAD Model
- Share
In Stock: 372
Can ship immediately
Pricing:
- 1$3.45
- 10$3.13154
- 100$2.68436
- 500$2.23697
- 1,000$1.9174
- 5,000$1.70009
- 10,000$1.66175
Quote It
Technical Details
- Series:850
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.050" (1.27mm)
- Number of Positions:3
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Unshrouded
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:0.100" (2.54mm)
- Contact Length - Post:0.122" (3.10mm)
- Overall Contact Length:0.303" (7.70mm)
- Insulation Height:0.084" (2.14mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:10.0µin (0.25µm)
- Contact Finish - Post:Gold
- Contact Material:Brass Alloy
- Insulation Material:Polyamide (PA46), Nylon 4/6
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
