0908160006
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER SMD 6POS 1.27MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0908160006 Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$1.04
- 10$0.911
- 25$0.8572
- 50$0.8214
- 100$0.7856
- 250$0.7142
- 500$0.64278
- 1,000$0.57136
- 2,500$0.5178
Quote It
Technical Details
- Series:Picoflex 90816
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Blade
- Pitch - Mating:0.050" (1.27mm)
- Number of Positions:6
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 2 Wall
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Latch Lock
- Contact Length - Mating:0.083" (2.10mm)
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.333" (8.45mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:118.1µin (3.00µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyphthalamide (PPA), Glass Filled
- Features:Board Guide
- Operating Temperature:-40°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 HB
- Insulation Color:Black
- Current Rating (Amps):1.2A
- Voltage Rating:250V
