0416720003

Woodhead - Molex
In Stock: 132

Can ship immediately

Pricing:
  • 1$0.63031
  • 3,600$0.63031

Quote It

Technical Details

  • Series:KK396, 41672
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header, Breakaway
  • Contact Type:Male Pin
  • Pitch - Mating:0.156" (3.96mm)
  • Number of Positions:4
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Shrouded - 1 Wall
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Friction Lock
  • Contact Length - Mating:0.450" (11.43mm)



  • Contact Length - Post:0.212" (5.38mm)
  • Overall Contact Length:-
  • Insulation Height:0.355" (9.02mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


1-1586587-2

CONN HEADER VERT 12POS 4.2MM

1-1586587-2 Datasheet
  • 1: $0.63045
  • 770: $0.63045

77315-401-15LF

CONN HEADER R/A 15POS 2.54MM

77315-401-15LF Datasheet
  • 1: $0.63053
  • 600: $0.58302

76382-408LF

CONN HEADER R/A 8POS 2.54MM

76382-408LF Datasheet
  • 1: $0.63054
  • 522: $0.58303

95278-401-12LF

CONN HEADER SMD 12POS 2.54MM

95278-401-12LF Datasheet
  • 1: $0.63054
  • 500: $0.58302

0559171030

2.0 WTB DUAL CONN DIP PLG HSG AS

  • 1: $0.63055

825437-7

CONN HEADER R/A 7POS 2.54MM

825437-7 Datasheet
  • 1: $0.63070
  • 4800: $0.61233

825435-7

CONN HEADER VERT 7POS 2.54MM

  • 1: $0.63078
  • 3000: $0.61241

350-10-104-00-012101

CONN HEADER VERT 4POS 1.78MM

350-10-104-00-012101 Datasheet
  • 1: $0.63088
  • 810: $0.55111

77313-802-22LF

CONN HEADER VERT 22POS 2.54MM

77313-802-22LF Datasheet
  • 1: $0.63100
  • 400: $0.58360

0026013192
