0346960102
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 10POS
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0346960102 Datasheet
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
- 1$1.6111
- 1,120$1.6111
Quote It
Technical Details
- Series:Stac64 34696
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Blade; Male Pin
- Pitch - Mating:-
- Number of Positions:10 (6 + 4 Power)
- Number of Rows:2
- Row Spacing - Mating:0.248" (6.30mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.110" (2.79mm)
- Overall Contact Length:-
- Insulation Height:0.868" (22.05mm)
- Contact Shape:Rectangular, Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Syndiotactic Polystyrene (SPS), Glass Filled
- Features:Board Guide
- Operating Temperature:-40°C ~ 100°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Brown
- Current Rating (Amps):-
- Voltage Rating:500V
