450-80-226-01-899101

Preci-Dip
In Stock: 183

Can ship immediately

Pricing:
  • 1$1.69329
  • 310$1.55919

Quote It

Technical Details

  • Series:450
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:26
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.141" (3.60mm)



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.110" (2.79mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
  • Features:-
  • Operating Temperature:-55°C ~ 125°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:150VDC

Related Products


2-2842276-0

20P,2MM,SHRD HDR,DRVT,SMD,0.76AU

  • 1: $1.69358

0311010040

CONN HEADER VERT 4POS 2.54MM

0311010040 Datasheet
  • 1: $1.69372
  • 1936: $1.69372

800-80-021-20-004101

CONN HEADER R/A 21POS 2.54MM

800-80-021-20-004101 Datasheet
  • 1: $1.69384
  • 310: $1.55977

1-826656-5

CONN HEADER VERT 30POS 2.54MM

1-826656-5 Datasheet
  • 1: $1.69385
  • 3000: $1.64452

0901310771
