In Stock: 137

Can ship immediately

Pricing:
  • 1$2.28732
  • 1,700$2.28732

Quote It

Technical Details

  • Series:BergCon®
  • Package:Tray
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:12
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.275" (6.99mm)



  • Contact Length - Post:0.103" (2.62mm)
  • Overall Contact Length:0.555" (14.10mm)
  • Insulation Height:0.500" (12.70mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold or Gold, GXT™
  • Contact Finish Thickness - Mating:30.0µin (0.76µm)
  • Contact Finish - Post:-
  • Contact Material:Phosphor Bronze
  • Insulation Material:Liquid Crystal Polymer (LCP), Glass Filled
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:-
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


350-80-136-00-006101

CONN HEADER VERT 36POS 2.54MM

350-80-136-00-006101 Datasheet
  • 1: $2.28743
  • 400: $2.10650

800-80-034-10-001101

CONN HEADER VERT 34POS 2.54MM

800-80-034-10-001101 Datasheet
  • 1: $2.28743
  • 400: $2.10650

450-80-236-00-006101

CONN HEADER VERT 36POS 2.54MM

450-80-236-00-006101 Datasheet
  • 1: $2.28744
  • 250: $2.10652

0424920344

CONN HEADER R/A 10POS 3.96MM

0424920344 Datasheet
  • 1: $2.28752
  • 1000: $2.28752

3-647271-1

CONN HEADER VERT 6POS 3.96MM

3-647271-1 Datasheet
  • 1: $2.28773
  • 750: $2.28773

0022283311

CONN HEADER VERT 31POS 2.54MM

0022283311 Datasheet
  • 1: $2.28774
  • 1500: $2.28774

0022283317

CONN HEADER VERT 31POS 2.54MM

0022283317 Datasheet
  • 1: $2.28774
  • 1500: $2.28774

20021521-00010C8LF

CONN HEADER SMD 10POS 1.27MM

20021521-00010C8LF Datasheet
  • 1: $2.28781
  • 1400: $2.28781

GBC04DGAN-M40

CONN HEADER SMD R/A 8POS 2.54MM

GBC04DGAN-M40 Datasheet
  • 1: $2.28800
  • 100: $2.28800

147324-5
