M80-7710442

Harwin
In Stock: 166

Can ship immediately

Pricing:
  • 1$2.7376
  • 1,024$2.5288

Quote It

Technical Details

  • Series:Datamate L-Tek
  • Package:Tube
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Positions:4
  • Number of Rows:2
  • Row Spacing - Mating:0.079" (2.00mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Latch Lock
  • Contact Length - Mating:-



  • Contact Length - Post:0.177" (4.50mm)
  • Overall Contact Length:-
  • Insulation Height:0.235" (5.97mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:29.5µin (0.75µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Polyphenylene Sulfide (PPS), Glass Filled
  • Features:Strain Relief Clips
  • Operating Temperature:-55°C ~ 125°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):2.2A per Contact
  • Voltage Rating:120V

Related Products


SMH100-LPPE-S41-SC-BK

CONN HEADER SMD 41POS 1MM

SMH100-LPPE-S41-SC-BK Datasheet
  • 1: $2.73789
  • 1000: $2.73789

SMH100-LPPE-S41-SD-BK

CONN HEADER SMD 41POS 1MM

SMH100-LPPE-S41-SD-BK Datasheet
  • 1: $2.73789
  • 1000: $2.73789

0877593615

CONN HEADER SMD 36POS 2MM

0877593615 Datasheet
  • 1: $2.73857
  • 630: $2.66033

351-80-121-00-005101

CONN HEADER VERT 21POS 2.54MM

351-80-121-00-005101 Datasheet
  • 1: $2.73862
  • 210: $2.52200

5-794627-2

CONN HEADER SMD R/A 22POS 3MM

5-794627-2 Datasheet
  • 1: $2.73874
  • 4800: $2.60832

4-2842279-8

48P,2MM,SHRD HDR,DRVT,SMD,0.38AU

  • 1: $2.73883

5-103165-3

CONN HEADER R/A 14POS 2.54MM

5-103165-3 Datasheet
  • 1: $2.73902
  • 1344: $2.30238

69155-110LF

CONN HEADER R/A 10POS 2.54MM

69155-110LF Datasheet
  • 1: $2.73952
  • 1600: $2.73952

69155-110

CONN HEADER R/A 10POS 2.54MM

69155-110 Datasheet
  • 1: $2.73952
  • 1600: $2.73952

0717640012
