In Stock: 135

Can ship immediately

Pricing:
  • 1$2.88218
  • 392$2.88218

Quote It

Technical Details

  • Series:AMPMODU MTE
  • Package:Tube
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:14
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Latch Holder
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:0.145" (3.68mm)
  • Overall Contact Length:-
  • Insulation Height:0.200" (5.08mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin-Lead
  • Contact Material:Brass
  • Insulation Material:Thermoplastic
  • Features:Board Lock, Keying Slot
  • Operating Temperature:-65°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


0702871180

CONN HEADER VERT 70POS 2.54MM

0702871180 Datasheet
  • 1: $2.88246
  • 1000: $2.88246

77313-152-22LF

CONN HEADER VERT 22POS 2.54MM

77313-152-22LF Datasheet
  • 1: $2.88268
  • 600: $2.66542

68585-006

CONN HEADER VERT 20POS 2.54MM

68585-006 Datasheet
  • 1: $2.88269
  • 510: $2.66545

350-80-124-00-012101

CONN HEADER VERT 24POS 1.78MM

350-80-124-00-012101 Datasheet
  • 1: $2.88320
  • 200: $2.65510

6-147279-0
