In Stock: 182

Can ship immediately

Pricing:
  • 1$2.92118
  • 228$2.70101

Quote It

Technical Details

  • Series:Dubox™
  • Package:Tube
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:22
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 2 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Friction Lock
  • Contact Length - Mating:0.197" (5.00mm)



  • Contact Length - Post:0.134" (3.40mm)
  • Overall Contact Length:-
  • Insulation Height:0.368" (9.35mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold, GXT™
  • Contact Finish Thickness - Mating:30.0µin (0.76µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Polyester, Glass Filled
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Blue
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


95278-402B48LF

CONN HEADER SMD 48POS 2.54MM

95278-402B48LF Datasheet
  • 1: $2.92119
  • 135: $2.70104

76383-417LF

CONN HEADER R/A 34POS 2.54MM

76383-417LF Datasheet
  • 1: $2.92120
  • 192: $2.70099

68481-172H
