TN2-L2-24V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 1A 24VDC
- Category
- Datasheet TN2-L2-24V Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TN
- Package:Tube
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):1 A
- Switching Voltage:125VAC, 110VDC - Max
- Coil Current:12.5 mA
- Coil Type:Latching, Dual Coil
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:-
- Operate Time:3 ms
- Release Time:3 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver (Ag), Gold (Au)
- Relay Type:General Purpose
