RZ03-1C4-D005
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 16A 5V
- Category
- Datasheet RZ03-1C4-D005 Datasheet
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$2.13
- 20$1.99841
- 40$1.77637
- 60$1.68756
- 100$1.59873
- 260$1.42109
- 500$1.33228
- 1,000$1.24346
- 5,000$1.19905
Quote It
Technical Details
- Series:RZ, SCHRACK
- Package:Tube
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:5VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):16 A
- Switching Voltage:400VAC - Max
- Coil Current:84 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:Class F
- Must Operate Voltage:3.5 VDC
- Must Release Voltage:0.5 VDC
- Operate Time:8 ms
- Release Time:6 ms
- Operating Temperature:-40°C ~ 85°C
- Contact Material:Silver Nickel (AgNi)
- Relay Type:General Purpose
