JS1F-24V-F
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 10A 24V
- Category
- Datasheet JS1F-24V-F Datasheet
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
- 1$1.82
- 10$1.71
- 25$1.52
- 50$1.444
- 100$1.368
- 250$1.216
- 500$1.14
- 1,000$1.064
- 5,000$1.026
Quote It
Technical Details
- Series:JS
- Package:Bulk
- Part Status:Not For New Designs
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):10 A
- Switching Voltage:250VAC, 100VDC - Max
- Coil Current:15 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Flux Protection
- Coil Insulation:-
- Must Operate Voltage:16.8 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:10 ms
- Release Time:10 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
