JTN1S-PA-F-DC48V

Panasonic
  • Lifecycle status Active
  • RoHS RoHS Compliant
  • DescriptionRELAY GEN PURPOSE SPDT 20A 48V
  • Category
  • Datasheet JTN1S-PA-F-DC48V Datasheet
  • ECAD Model
  • Share
In Stock: 178

Can ship immediately

Pricing:
  • 1$4.97
  • 10$4.65988
  • 25$4.14167
  • 50$3.93458
  • 100$3.7275
  • 250$3.31333
  • 500$3.10625
  • 1,000$2.89917

Quote It

Technical Details

  • Series:JT-N
  • Package:Bulk
  • Part Status:Not For New Designs
  • Mounting Type:Through Hole
  • Coil Voltage:48VDC
  • Contact Form:SPDT (1 Form C)
  • Contact Rating (Current):20 A
  • Switching Voltage:277VAC - Max
  • Coil Current:16.7 mA
  • Coil Type:Non Latching
  • Features:-



  • Termination Style:PC Pin
  • Seal Rating:Sealed - Fully
  • Coil Insulation:Class F
  • Must Operate Voltage:36 VDC
  • Must Release Voltage:4.8 VDC
  • Operate Time:20 ms
  • Release Time:10 ms
  • Operating Temperature:-55°C ~ 85°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
