T9GS5L14-9
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 20A 9V
- Category
- Datasheet T9GS5L14-9 Datasheet
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$3.36
- 10$3.14743
- 25$2.79771
- 50$2.65783
- 100$2.51794
- 250$2.23817
- 500$2.09829
- 1,000$1.9584
Quote It
Technical Details
- Series:T9G
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:9VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):20 A
- Switching Voltage:480VAC - Max
- Coil Current:100 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:Class F
- Must Operate Voltage:6.75 VDC
- Must Release Voltage:0.9 VDC
- Operate Time:15 ms
- Release Time:22 ms
- Operating Temperature:-40°C ~ 105°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
