DSP1A-L-DC5V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GENERAL PURPOSE SPST 8A 5V
- Category
- Datasheet DSP1A-L-DC5V Datasheet
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
- 1$3.648
- 50$3.648
Quote It
Technical Details
- Series:DSP
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:5VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):8 A
- Switching Voltage:250VAC, 30VDC - Max
- Coil Current:30 mA
- Coil Type:Latching, Single Coil
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:-
- Must Operate Voltage:4 VDC
- Must Release Voltage:-
- Operate Time:10 ms
- Release Time:5 ms
- Operating Temperature:-40°C ~ 60°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
