JQ1P-9V-F
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 10A 9V
- Category
- Datasheet JQ1P-9V-F Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
- 1$4.99
- 10$4.68
- 25$4.16
- 50$3.952
- 100$3.744
- 250$3.328
- 500$3.12
- 1,000$2.912
Quote It
Technical Details
- Series:JQ
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:9VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):10 A
- Switching Voltage:250VAC, 110VDC - Max
- Coil Current:44.4 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:Class E
- Must Operate Voltage:7.2 VDC
- Must Release Voltage:0.45 VDC
- Operate Time:20 ms
- Release Time:10 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
