HE1AN-S-AC48V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPST 30A 48V
- Category
- Datasheet HE1AN-S-AC48V Datasheet
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
- 1$28.006
- 20$28.006
Quote It
Technical Details
- Series:HE
- Package:Bulk
- Part Status:Active
- Mounting Type:Chassis Mount
- Coil Voltage:48VAC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):30 A
- Switching Voltage:277VAC, 30VDC - Max
- Coil Current:39 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Screw Terminal
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:33.6 VAC
- Must Release Voltage:7.2 VAC
- Operate Time:30 ms
- Release Time:30 ms
- Operating Temperature:-50°C ~ 55°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
