J115F21AL12VDCS.9
CIT Relay and Switch
In Stock: 151
Can ship immediately
Pricing:
- 1$1.36
Quote It
Technical Details
- Series:J115F2
- Package:Tube
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:12VDC
- Contact Form:SPST-NO (1 Form A)
- Contact Rating (Current):40 A
- Switching Voltage:277VAC, 110VDC - Max
- Coil Current:75 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin, Quick Connect - 0.250" (6.3mm)
- Seal Rating:Sealed - Fully
- Coil Insulation:Class F
- Must Operate Voltage:9 VDC
- Must Release Voltage:1.2 VDC
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-55°C ~ 125°C
- Contact Material:Silver Tin Oxide (AgSnO)
- Relay Type:General Purpose
