AHN22124
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 5A 24V
- Category
- Datasheet AHN22124 Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:AHN
- Package:Tube
- Part Status:Obsolete
- Mounting Type:Socketable
- Coil Voltage:24VDC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):5 A
- Switching Voltage:250VAC, 30VDC - Max
- Coil Current:22 mA
- Coil Type:Non Latching
- Features:Lighted Indicator
- Termination Style:Plug In
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:16.8 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:15 ms
- Release Time:5 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Nickel (AgNi)
- Relay Type:General Purpose
