T90N5D12-18
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE SPDT 20A 18V
- Category
- Datasheet T90N5D12-18 Datasheet
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
- 1$7.44
- 10$6.975
- 25$6.2
- 50$5.89
- 100$5.58
- 250$4.96
- 500$4.65
- 1,000$4.34
Quote It
Technical Details
- Series:T90
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Through Hole
- Coil Voltage:18VDC
- Contact Form:SPDT (1 Form C)
- Contact Rating (Current):20 A
- Switching Voltage:240VAC, 28VDC - Max
- Coil Current:47 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:-
- Coil Insulation:Class F
- Must Operate Voltage:13.5 VDC
- Must Release Voltage:1.8 VDC
- Operate Time:15 ms
- Release Time:15 ms
- Operating Temperature:-55°C ~ 85°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
