PCL-403DS,000
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE 4PDT 3A 24V
- Category
- Datasheet PCL-403DS,000 Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PCL, OEG
- Package:Tray
- Part Status:Obsolete
- Mounting Type:Socketable
- Coil Voltage:24VDC
- Contact Form:4PDT (4 Form C)
- Contact Rating (Current):3 A
- Switching Voltage:250VAC, 24VDC - Max
- Coil Current:37.5 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Plug In
- Seal Rating:-
- Coil Insulation:Class F
- Must Operate Voltage:19.2 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:15 ms
- Release Time:8 ms
- Operating Temperature:-40°C ~ 55°C
- Contact Material:Silver (Ag)
- Relay Type:General Purpose
