- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE 3PDT 10A 24V
- Category
- Datasheet PT380024 Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PT, SCHRACK
- Package:Bulk
- Part Status:Discontinued at Digi-Key
- Mounting Type:Socketable
- Coil Voltage:24VDC
- Contact Form:3PDT (3 Form C)
- Contact Rating (Current):10 A
- Switching Voltage:400VAC - Max
- Coil Current:30.8 mA
- Coil Type:Non Latching
- Features:Mechanical Indicator, Test Button
- Termination Style:Plug In, Quick Connect - 0.110" (2.8mm)
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:2.4 VDC
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-40°C ~ 70°C
- Contact Material:Silver Nickel (AgNi)
- Relay Type:General Purpose
