OSA-SH-224DM3,000
TE Connectivity Potter & Brumfield Relays
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPST 3A 24V
- Category
- Datasheet OSA-SH-224DM3,000 Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:OSA, OEG
- Package:Bulk
- Part Status:Active
- Mounting Type:Through Hole
- Coil Voltage:24VDC
- Contact Form:DPST-NO (2 Form A)
- Contact Rating (Current):3 A
- Switching Voltage:240VAC, 30VDC - Max
- Coil Current:22.5 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:PC Pin
- Seal Rating:Sealed - Fully
- Coil Insulation:-
- Must Operate Voltage:18 VDC
- Must Release Voltage:1.2 VDC
- Operate Time:20 ms
- Release Time:10 ms
- Operating Temperature:-30°C ~ 60°C
- Contact Material:Silver Alloy
- Relay Type:General Purpose
