8690780000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRELAY GEN PURPOSE DPDT 16A 230V
- Category
- Datasheet 8690780000 Datasheet
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:RPW
- Package:Bulk
- Part Status:Obsolete
- Mounting Type:Socketable
- Coil Voltage:230VAC
- Contact Form:DPDT (2 Form C)
- Contact Rating (Current):16 A
- Switching Voltage:440VAC - Max
- Coil Current:10.1 mA
- Coil Type:Non Latching
- Features:-
- Termination Style:Plug In, Quick Connect - 0.250" (6.3mm)
- Seal Rating:-
- Coil Insulation:-
- Must Operate Voltage:184 VAC
- Must Release Voltage:69 VAC
- Operate Time:15 ms
- Release Time:10 ms
- Operating Temperature:-45°C ~ 60°C
- Contact Material:Silver Cadmium Oxide (AgCdO)
- Relay Type:General Purpose
