9075-0-00-21-00-00-03-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN
- CategoryTerminals - PC Pin, Single Post Connectors
- Datasheet 9075-0-00-21-00-00-03-0 Datasheet
-
ECAD Model
- Share
In Stock: 172
Can ship immediately
Pricing:
- 1$0.52944
- 1,000$0.52128
Quote It
Technical Details
- Series:9075
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Wire
- Pin Size - Above Flange:0.012" (0.30mm) Dia
- Pin Size - Below Flange:0.012" (0.31mm) Dia
- Length - Above Flange:0.230" (5.84mm)
- Length - Below Flange:0.075" (1.91mm)
- Length - Overall:0.210" (5.33mm)
- Flange Diameter:0.036" (0.91mm)
- Mounting Hole Diameter:0.034" (0.86mm)
- Mounting Type:Through Hole
- Termination:Press-Fit
- Insulation:Non-Insulated
- Board Thickness:-
- Contact Material:Brass Alloy
- Contact Finish:Gold
- Contact Finish Thickness:20.0µin (0.51µm)
