SN74HC4852N
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSN74HC4852 DUAL 4-TO-1 CHANNEL A
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 25,106
Can ship immediately
Pricing:
- 1$0.29
- 10$0.25631
- 25$0.2407
- 100$0.19639
- 500$0.15524
- 1,000$0.12419
- 2,500$0.11255
- 5,000$0.10478
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Switch Circuit:SP4T
- Multiplexer/Demultiplexer Circuit:4:1
- Number of Circuits:2
- On-State Resistance (Max):195Ohm
- Channel-to-Channel Matching (ΔRon):3Ohm
- Voltage - Supply, Single (V+):2V ~ 6V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):39ns, 78ns
- -3db Bandwidth:-
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):22pF
- Current - Leakage (IS(off)) (Max):200nA
- Crosstalk:-
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
