MAX4642EUA+TG104
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH DUAL SPST 8UMAX
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4642EUA+TG104 Datasheet
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:2
- On-State Resistance (Max):4Ohm
- Channel-to-Channel Matching (ΔRon):200mOhm
- Voltage - Supply, Single (V+):1.8V ~ 5.5V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):15ns, 8ns
- -3db Bandwidth:-
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):7pF, 7pF
- Current - Leakage (IS(off)) (Max):250pA
- Crosstalk:-97dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package:8-uMAX
