MAX4800CTM+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH OCTAL SPST 48TQFN
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4800CTM+T Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:8
- On-State Resistance (Max):38Ohm
- Channel-to-Channel Matching (ΔRon):1.9Ohm
- Voltage - Supply, Single (V+):2.7V ~ 13.2V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):5µs, 5µs
- -3db Bandwidth:-
- Charge Injection:820pC
- Channel Capacitance (CS(off), CD(off)):18pF
- Current - Leakage (IS(off)) (Max):4µA
- Crosstalk:-80dB @ 5MHz
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Package / Case:48-WFQFN Exposed Pad
- Supplier Device Package:48-TQFN-EP (6x6)
