17001156A
Comair Rotron- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN DC IP68 MSD12B3E2X-E3
- CategoryDC Brushless Fans (BLDC)
- Datasheet 17001156A Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
- 1$45.6012
- 10$41.69635
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 120mm L x 120mm H
- Width:38.10mm
- Air Flow:110.0 CFM (3.08m³/min)
- Static Pressure:-
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Auto Restart, Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
- Noise:49.1dB(A)
- Power (Watts):7 W
- RPM:3000 RPM
- Termination:4 Wire Leads
- Ingress Protection:IP68 - Dust Tight, Waterproof
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, cUL, UL
- Weight:-
