2N6036G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPOWER BIPOLAR TRANSISTOR, 4A, 80
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet 2N6036G Datasheet
-
ECAD Model
- Share
In Stock: 11,690
Can ship immediately
Pricing:
- 1$0.27
- 10$0.23635
- 100$0.18117
- 500$0.14323
- 1,000$0.11458
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:PNP - Darlington
- Current - Collector (Ic) (Max):4 A
- Voltage - Collector Emitter Breakdown (Max):80 V
- Vce Saturation (Max) @ Ib, Ic:3V @ 40mA, 4A
- Current - Collector Cutoff (Max):100µA
- DC Current Gain (hFE) (Min) @ Ic, Vce:750 @ 2A, 3V
- Power - Max:40 W
- Frequency - Transition:-
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-225AA, TO-126-3
- Supplier Device Package:TO-225AA
