AUIRLR3114ZTRL

Technical Details

• Series:HEXFET®
• Package:Bulk
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):40 V
• Current - Continuous Drain (Id) @ 25°C:42A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):-
• Rds On (Max) @ Id, Vgs:4.9mOhm @ 42A, 10V
• Vgs(th) (Max) @ Id:2.5V @ 100µA

• Gate Charge (Qg) (Max) @ Vgs:56 nC @ 4.5 V
• Vgs (Max):-
• Input Capacitance (Ciss) (Max) @ Vds:3810 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):140W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:D-PAK (TO-252AA)
• Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
