NTK3043NT5G

Technical Details

• Series:-
• Package:Bulk
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:210mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):1.65V, 4.5V
• Rds On (Max) @ Id, Vgs:3.4Ohm @ 10mA, 4.5V
• Vgs(th) (Max) @ Id:1.3V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±10V
• Input Capacitance (Ciss) (Max) @ Vds:11 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):310mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:SOT-723
• Package / Case:SOT-723
