FDN5630
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSMALL SIGNAL FIELD-EFFECT TRANSI
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FDN5630 Datasheet
-
ECAD Model
- Share
In Stock: 126,013
Can ship immediately
Pricing:
- 1$0.16
- 3,000$0.05111
- 6,000$0.04781
- 15,000$0.04451
- 30,000$0.0422
- 75,000$0.04197
Quote It
Technical Details
- Series:PowerTrench®
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:1.7A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):6V, 10V
- Rds On (Max) @ Id, Vgs:100mOhm @ 1.7A, 10V
- Vgs(th) (Max) @ Id:3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:10 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:400 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):500mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:SuperSOT-3
- Package / Case:TO-236-3, SC-59, SOT-23-3
