FDG327NZ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 20V 1.5A SC88
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FDG327NZ Datasheet
-
ECAD Model
- Share
In Stock: 37,837
Can ship immediately
Pricing:
- 1$0.27
- 3,000$0.25302
- 6,000$0.2367
- 15,000$0.22037
- 30,000$0.20895
Quote It
Technical Details
- Series:PowerTrench®
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:1.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:90mOhm @ 1.5A, 4.5V
- Vgs(th) (Max) @ Id:1.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:6 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:412 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):420mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:SC-88 (SC-70-6)
- Package / Case:6-TSSOP, SC-88, SOT-363
