FDME910PZT
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSMALL SIGNAL FIELD-EFFECT TRANSI
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FDME910PZT Datasheet
-
ECAD Model
- Share
In Stock: 32,913
Can ship immediately
Pricing:
- 1$0.28
- 5,000$0.28
- 10,000$0.26963
- 25,000$0.26397
Quote It
Technical Details
- Series:PowerTrench®
- Package:Bulk
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:8A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:24mOhm @ 8A, 4.5V
- Vgs(th) (Max) @ Id:1.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:21 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:2.11 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):2.1W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:MicroFet 1.6x1.6 Thin
- Package / Case:6-PowerUFDFN
