NTD3055-094T4G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPOWER FIELD-EFFECT TRANSISTOR, 1
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NTD3055-094T4G Datasheet
-
ECAD Model
- Share
In Stock: 19,212
Can ship immediately
Pricing:
- 1$0.27
- 2,500$0.27
- 5,000$0.25138
- 12,500$0.24207
- 25,000$0.23699
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:12A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:94mOhm @ 6A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:20 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:450 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):1.5W (Ta), 48W (Tj)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:DPAK
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
