FDS6675
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 30V 11A 8SOIC
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FDS6675 Datasheet
-
ECAD Model
- Share
In Stock: 58,974
Can ship immediately
Pricing:
- 1$0.9
- 2,500$0.80604
- 5,000$0.76796
- 12,500$0.74076
Quote It
Technical Details
- Series:PowerTrench®
- Package:Bulk
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:11A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:14mOhm @ 11A, 10V
- Vgs(th) (Max) @ Id:3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:42 nC @ 5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:3 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):2.5W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-SOIC
- Package / Case:8-SOIC (0.154", 3.90mm Width)
