PMZ950UPELYL
Nexperia
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 500MA DFN1006-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet PMZ950UPELYL Datasheet
-
ECAD Model
- Share
In Stock: 199
Can ship immediately
Pricing:
- 1$0.4
- 10,000$0.08442
- 30,000$0.0798
- 50,000$0.07195
- 100,000$0.07056
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:500mA (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.5V, 4.5V
- Rds On (Max) @ Id, Vgs:1.4Ohm @ 500mA, 4.5V
- Vgs(th) (Max) @ Id:950mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:2.1 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:43 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):360mW (Ta), 2.7W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:DFN1006-3
- Package / Case:SC-101, SOT-883
