NTMJS0D8N04CLTWG
ON Semiconductor- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 40V 56A/368A 8LFPAK
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 123
Can ship immediately
Pricing:
- 1$2.29
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):40 V
- Current - Continuous Drain (Id) @ 25°C:56A (Ta), 368A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:720µOhm @ 50A, 10V
- Vgs(th) (Max) @ Id:2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:162 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:9600 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):4.2W (Ta), 180W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-LFPAK
- Package / Case:SOT-1205, 8-LFPAK56
