2SK2624ALS

Technical Details

• Series:-
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):600 V
• Current - Continuous Drain (Id) @ 25°C:3.5A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):-
• Rds On (Max) @ Id, Vgs:2.6Ohm @ 1.8A, 15V
• Vgs(th) (Max) @ Id:-

• Gate Charge (Qg) (Max) @ Vgs:15 nC @ 10 V
• Vgs (Max):-
• Input Capacitance (Ciss) (Max) @ Vds:550 pF @ 20 V
• FET Feature:-
• Power Dissipation (Max):2W (Ta), 25W (Tc)
• Operating Temperature:150°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-220FI(LS)
• Package / Case:TO-220-3 Full Pack
