ZXM64P02XTC
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 3.5A 8MSOP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet ZXM64P02XTC Datasheet
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:3.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):2.7V, 4.5V
- Rds On (Max) @ Id, Vgs:90mOhm @ 2.4A, 4.5V
- Vgs(th) (Max) @ Id:700mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:6.9 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:900 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):1.1W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-MSOP
- Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
