TK16J60W,S1VQ
Toshiba Electronic Devices and Storage Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 15.8A TO3P
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet TK16J60W,S1VQ Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:DTMOSIV
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:15.8A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:190mOhm @ 7.9A, 10V
- Vgs(th) (Max) @ Id:3.7V @ 790µA
- Gate Charge (Qg) (Max) @ Vgs:38 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:1350 pF @ 300 V
- FET Feature:Super Junction
- Power Dissipation (Max):130W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-3P(N)
- Package / Case:TO-3P-3, SC-65-3
