MCP87030T-U/MF
Microchip Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 25V 100A 8PDFN
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet MCP87030T-U/MF Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):25 V
- Current - Continuous Drain (Id) @ 25°C:100A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:3.5mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id:1.6V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:22 nC @ 4.5 V
- Vgs (Max):+10V, -8V
- Input Capacitance (Ciss) (Max) @ Vds:1635 pF @ 12.5 V
- FET Feature:-
- Power Dissipation (Max):2.2W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-PDFN (5x6)
- Package / Case:8-PowerTDFN
